Specifications
Specifications
- Manufacturer: Ski-Doo
- Model: Expedition Xtreme
- Year: 2020
- Type: Expedition
Rotax engine
- Engine: ROTAX 850 E-TEC
- Engine details: Liquid-cooled, two-stoke, eRAVE™
- Cylinders: 2
- Displacement: 849 cc / 51.9 in.³
- Bore: 82 mm / 3.2 in.
- Stroke: 80.4 mm / 3.2 in.
- Maximum engine speed: 7,900 RPM
- Carburation: E-TEC® direct injection with additional booster injectors
- Recommended fuel type: Premium unleaded
- Minimum octane: 91
- Fuel tank: 42 L / 11.1 US gal
- Oil tank capacity: 3.4 L / 3.6 qt
Powertrain
- Drive clutch type: pDrive™ with clickers
- Driven clutch type: QRS
- Engagement: 3,800 RPM
- Small sprocket number of teeth: Lo = 3.59:1 ratio
- Large sprocket number of teeth: Hi = 2.0:1 ratio
- Drive sprocket number of teeth: 8
- Drive sprocket diameter: 183 mm / 7.2 in.
- Brake system: Brembo brake with stainless-steel braided brake line
Dimensions
- Vehicle overall length: 3,336 mm / 131.3 in.
- Vehicle overall width: 1,140 to 1,180 mm / 44.9 to 46.5 in.
- Vehicle overall height: 1,299 mm / 51.1 in.
- Ski stance: 975 or 1,020 mm / 38.4 or 40.2 in.
- Ski overall length: 1,058 mm / 41.7 in.
- Track nominal width: 500 mm / 20 in.
- Track nominal length: 3,923 mm / 154 in.
- Track profile height: 45.7 mm / 1.8 in. Cobra WT
Suspension
- Front suspension: RAS™ 3
- Front shock: HPG™ Plus
- Front suspension max. travel: 220 mm / 8.7 in.
- Rear suspension: SC™-5U
- Center shock: HPG™ Plus
- Rear shock: KYB† Pro 36 Easy-Adjust
- Rear suspension max. travel: 239 mm / 9.4 in.
Features
- Frame: REV® Gen4
- Bodywork: Wide design
- Skis: Pilot™ DS 3
- Seating: 1-up modular with rear seat storage
- Handlebar: U-shaped aluminum with J-hooks / Low grab handle/ Flexible handguards
- Riser block height: 145 mm / 5.7 in.
- Starter: Electric
- Reverse: RER™
- Heated throttle lever: Standard
- Gauge: 4.5-in. digital display
- Mirrors: Optional
- Windshield: 360 mm / 14 in.
- Runner: Square 3/8
- Carbide configuration: 102 mm / 4 in. at 90°
- Hitch: Optional
