Specifications
Specifications
- Manufacturer: Ski-Doo
- Model: Expedition SE
- Year: 2020
- Type: Expedition
Rotax engine
- Engine: ROTAX 600R E-TEC
- Engine details: Liquid-cooled, two-stroke, eRAVE™
- Cylinders: 2
- Displacement: 599.4 cc / 36.6 in.³
- Bore: 72.3 mm / 2.85 in.
- Stroke: 73 mm / 2.87 in.
- Maximum engine speed: 8,100 RPM
- Carburation: E-TEC ® direct injection
- Recommended fuel type: Premium unleaded
- Minimum octane: 91
- Fuel tank: 42 L / 11.1 US gal
- Oil tank capacity: 3.4 L / 3.6 qt
Powertrain
- Engine: ROTAX 600R E-TEC
- Drive clutch type: pDrive™
- Driven clutch type: QRS
- Engagement: 3,400 RPM
- Small sprocket number of teeth: Lo = 3.87:1 ratio
- Large sprocket number of teeth: Hi = 2.15:1 ratio
- Drive sprocket number of teeth: 8
- Drive sprocket diameter: 183 mm / 7.2 in.
- Brake system: Brembo brake with stainless-steel braided brake line
Dry weight
- Engine: ROTAX 600R E-TEC
Dimensions
- Vehicle overall length: 3,336 mm / 131.3 in.
- Vehicle overall width: 1,140 to 1,180 mm / 44.9 to 46.5 in.
- Vehicle overall height: 1,405 mm / 55.3 in.
- Ski stance: 975 or 1,020 mm / 38.4 or 40.2 in.
- Ski overall length: 1,049 mm / 41.3 in.
- Track nominal width: 500 mm / 20 in.
- Track nominal length: 3,923 mm / 154 in.
- Track profile height: 38.1 mm / 1.5 in. Silent Cobra WT
- Optional track: 45.7 mm / 1.8 in. Cobras WT or 38.1 mm / 1.5 in. Silent Ice Cobra WT
Suspension
- Front suspension: RAS™ 3
- Front shock: Motion Control
- Front suspension max. travel: 201 mm / 8.3 in.
- Rear suspension: SC™-5U
- Center shock: Motion Control
- Rear shock: ACS (Air Control Suspension)
- Rear suspension max. travel: 239 mm / 9.4 in.
Features
- Frame: REV® Gen4
- Bodywork: Wide design
- Skis: Pilot™ DS 2
- Seating: 2-up modular with underseat storage
- Handlebar: U-shaped aluminum with J-hooks / Low grab handle
- Riser block height: Adjustable- 120 mm / 4.7 in.
- Starter: Electric
- Reverse: RER™ (600R E-TEC®)
Electro-mechanic (ACE™ engines) - Heated throttle lever/ grips: Standard (driver and passenger)
- Gauge: 7.2-in. wide digital display
- Mirrors: Standard
- Windshield: 673 mm / 26.5 in.
- Runner: Square 3/8
- Carbide configuration: 102 mm / 4 in. at 90°
- Hitch: Hitch receiver
